의료용절삭기구
관절경 시술 시 생체조직, 뼈 등을 절삭하기 위한 의료용 절삭기구로써, 절삭용 버(Burr)와 블레이드(Blade) 등을 포함하며 핸드피스에 연결하여 사용한다.
RealArthro™
Shaver Blades and Burrs for Real Arthroscopic surgery
Feature & Benefits
Designed to be better cutting performance, more convenient and most cost-effective. RealArthro™ shaver blades and burrs can both resect soft tissue and debride bone tissue.
-
Optimized Inner and Outer Balance
Minimized space between inner and outer cutters, increasing cutting efficiency and maintain safe rotation.
-
Stronger inner cutting Tip
Stronger inner cutting tips privide advanced cutting performance.
-
Connection Compatibility
RearArthro™ shaver blades and burrs can be compatible with the shaver systems from all three companies.
-
Color-coded hubs
Color coding denotes different type of blade tips.
관절경 수술에 최적화된 Shaver Burr 와 Blade
-
최적화된 밸런싱
내부와 외부 블레이드 사이에 공간을 최소화 하여 안정적인 회전을 하고 진동 및 소음이 발생 하지 않습니다
-
강력한 블레이드
열처리 되 칼날은 강력한 절삭기능과 오랫동안 유지되는 내마모성을 제공합니다.
-
다양한 호환성
RealArthro™ 쉐이버는 기존 3사의 모든 제품과 호환성을 제공합니다.
-
모델별 색상구분
블레이드 타입에 따라 직관적으로 구분할수있게 색상별로제공됩니다
-
RealArthro™ Lance Blade Excellent access to narrow and deep areas with ovoid outer window ideal for menisectomy.
-
RealArthro™ FR Blade Designed for both aggressive general tissue debridement and bone.
-
RealArthro™ Jag Blade Ideal for aggressive resection of soft tissue including synovium, cartilage, and plica.
-
RealArthro™ Dual-Jag Blade Idear for extensive soft-tissue debridement.
-
RealArthro™ Oval Burr Designed for rapid and aggressive bone resection.
-
RealArthro™ Round Burr Ideal for softs tissue, osteochondral and osteophyte resection, or bony site preparation.
| Product Name | Model number | Description | Working Length |
|---|---|---|---|
| RealArthro™ Lance Blade | JM-CM-LB04 | Ø 4.0mm | 130mm |
| JM-AT-LB04 | Ø 4.0mm | 130mm | |
| JM-ST-LB04 | Ø 4.0mm | 130mm | |
| RealArthro™ FR Blade | JM-CM-FR29 | Ø 2.9mm | 82mm |
| JM-AT-FR29 | Ø 2.9mm | 82mm | |
| JM-ST-FR29 | Ø 2.9mm | 82mm | |
| JM-CM-FR35 | Ø 3.5mm | 130mm | |
| JM-AT-FR35 | Ø 3.5mm | 130mm | |
| JM-ST-FR35 | Ø 3.5mm | 130mm | |
| JM-CM-FR04 | Ø 4.0mm | 130mm | |
| JM-AT-FR04 | Ø 4.0mm | 130mm | |
| JM-ST-FR04 | Ø 4.0mm | 130mm | |
| RealArthro™ Jag Blade | JM-CM-JB29 | Ø 2.9mm | 82mm |
| JM-AT-JB29 | Ø 2.9mm | 82mm | |
| JM-ST-JB29 | Ø 2.9mm | 82mm | |
| JM-CM-JB35 | Ø 3.5mm | 130mm | |
| JM-AT-JB35 | Ø 3.5mm | 130mm | |
| JM-ST-JB35 | Ø 3.5mm | 130mm | |
| JM-CM-JB04 | Ø 4.0mm | 130mm | |
| JM-AT-JB04 | Ø 4.0mm | 130mm | |
| JM-ST-JB04 | Ø 4.0mm | 130mm | |
| RealArthro™ Dual-Jag Blade | JM-CM-DJ29 | Ø 2.9mm | 82mm |
| JM-AT-DJ29 | Ø 2.9mm | 82mm | |
| JM-ST-DJ29 | Ø 2.9mm | 82mm | |
| JM-CM-DJ35 | Ø 3.5mm | 130mm | |
| JM-AT-DJ35 | Ø 3.5mm | 130mm | |
| JM-ST-DJ35 | Ø 3.5mm | 130mm | |
| JM-CM-DJ04 | Ø 4.0mm | 130mm | |
| JM-AT-DJ04 | Ø 4.0mm | 130mm | |
| JM-ST-DJ04 | Ø 4.0mm | 130mm | |
| RealArthro™ Oval Burr | JM-CM-OB04 | Ø 4.0mm | 130mm |
| JM-AT-OB04 | Ø 4.0mm | 130mm | |
| JM-ST-OB04 | Ø 4.0mm | 130mm | |
| RealArthro™ Round Burr | JM-CM-RB04 | Ø 4.0mm | 130mm |
| JM-AT-RB04 | Ø 4.0mm | 130mm | |
| JM-ST-RB04 | Ø 4.0mm | 130mm |
